FISHBONE

Fishbone, which can be expanded with panels connected to vertical connecting pipes, allows to create working areas at different angles according to type of fittings. With its horizontally partitioned structure, it allows the use of different materials such as melamine, fabric, acoustic felt or plexiglass. Partially or completely isolated areas can be created with height options, and different usage scenarios can be created with varying panel widths and table lengths. Thanks to the cabling system passing through the panel and the electrical power supply that can be accessed through the panel, it provides a clean and tidy working area away from clutter. While meeting and individual workspaces are created with the rectangular table that can be mounted on the panels, honeycomb-shaped workspaces can be created with trapezoidal tabletops. In addition to individual or teamwork setups in open workspaces, it also offers solutions suitable for common use such as call centers, libraries, and lobbies.

ÖZGE ÇAĞLA AKTAŞ

The Fishbone panel family has been developed to create private areas in workspaces. Its modular structure, which allows for countless combinations, can be added end-to-end in accordance with the area it will be used, providing flexible solutions. In open offices; it creates isolated workspaces that are free from distracting visual and audio problems and are suitable for focusing.
CONFIGURATOR FUNCTION VIDEO IMAGE

COLORS

ACT 02 Orange ACT 03 Red ACT 04 Burgundy ACT 05 Rosa ACT 07 Pink ACT 08 Caramel ACT 11 Light Brown ACT 13 Yellow ACT 15 Brown ACT 17 Sage ACT 18 Olive Oil ACT 20 Mint ACT 21 Pistachio Green ACT 23 Turquoise ACT 24 Dark Blue ACT 26 Denim ACT 27 Blue ACT 28 Grey ACT 29 Smoked ACT 30 Anthracite ACT 31 Black

DOWNLOADABLE
DOCUMENTS

TECHNICAL DOCUMENT
* Please use the
Architect Login to download and analyze 2D and 3D files.

TECHNICAL INFORMATION

Two-Section Panel

H : 120
W : 4,4
L : 71

Two-Section Panel

H : 120
W : 4,4
L : 81

Two-Section Panel

H : 120
W : 4,4
L : 101

Two-Section Panel

H : 120
W : 4,4
L : 121

Two-Section Panel

H : 120
W : 4,4
L : 141

Two-Section Panel

H : 120
W : 4,4
L : 161

Two-Section Panel With Electrical Option

H : 120
W : 4,4
L : 71

Two-Section Panel With Electrical Option

H : 120
W : 4,4
L : 81

Two-Section Panel With Electrical Option

H : 120
W : 4,4
L : 101

Two-Section Panel With Electrical Option

H : 120
W : 4,4
L : 141

Two-Section Panel With Electrical Option

H : 120
W : 4,4
L : 161

Three-Section Panel

H : 166,5
W : 4,4
L : 71

Three-Section Panel

H : 166,5
W : 4,4
L : 81

Three-Section Panel

H : 166,5
W : 4,4
L : 101

Three-Section Panel

H : 166,5
W : 4,4
L : 121

Three-Section Panel

H : 166,5
W : 4,4
L : 141

Three-Section Panel

H : 166,5
W : 4,4
L : 161

Three-Section Panel With Electrical Option

H : 166,5
W : 4,4
L : 71

Three-Section Panel With Electrical Option

H : 166,5
W : 4,4
L : 81

Three-Section Panel With Electrical Option

H : 166,5
W : 4,4
L : 101

Three-Section Panel With Electrical Option

H : 166,5
W : 4,4
L : 121

Three-Section Panel With Electrical Option

H : 166,5
W : 4,4
L : 141

Three-Section Panel With Electrical Option

H : 166,5
W : 4,4
L : 161

Taple Top Panel

H : 36
W : 4
L : 60

Taple Top Panel

H : 36
W : 3,4
L : 70

Taple Top Panel

H : 36
W : 3,4
L : 80

Taple Top Panel

H : 36
W : 3,4
L : 100

Taple Top Panel

H : 36
W : 3,4
L : 120

Taple Top Panel

H : 36
W : 3,4
L : 140

Taple Top Panel

H : 36
W : 3,4
L : 160

Taple Top Panel

H : 36
W : 3,4
L : 180

Vertical End Profile

H : 120
Ø : 42

Vertical Connection Profile

H : 120
Ø : 42

90º Two Way

90º Three Way

90º Four Way

120º Two Way

120º Three Way

180º Two Wayi

Single Finish

Rectangle Table Top

H : 1,8
W : 60
L : 100

Rectangle Table Top

H : 1,8
W : 60
L : 120

Rectangle Table Top

H : 1,8
W : 60
L : 140

Rectangle Table Top

H : 1,8
W : 60
L : 160

Rectangle Table TopWith Grommet

H : 1,8
W : 60
L : 100

Rectangle Table TopWith Grommet

H : 1,8
W : 60
L : 120

Rectangle Table TopWith Grommet

H : 1,8
W : 60
L : 140

Rectangle Table TopWith Grommet

H : 1,8
W : 60
L : 160

Rectangle Table Top

H : 1,8
W : 70
L : 100

Rectangle Table Top

H : 1,8
W : 70
L : 120

Rectangle Table Top

H : 1,8
W : 70
L : 140

Rectangle Table Top

H : 1,8
W : 70
L : 160

Rectangle Table TopWith Grommet

H : 1,8
W : 70
L : 100

Rectangle Table TopWith Grommet

H : 1,8
W : 70
L : 120

Rectangle Table TopWith Grommet

H : 1,8
W : 70
L : 140

Rectangle Table TopWith Grommet

H : 1,8
W : 70
L : 160

Trapeze Table Top

H : 1,8
W1 : 60
W2 : 69,3
L1 : 140
L2 : 71,5

Trapeze Table Top

H : 1,8
W1 : 60
W2 : 69,3
L1 : 150
L2 : 81,5

Trapeze Table Top

H : 1,8
W1 : 60
W2 : 69,3
L1 : 170
L2 : 101,5

Trapeze Table Top With Grommet

H : 1,8
W1 : 60
W2 : 69,3
L1 : 140
L2 : 71,5

Trapeze Table Top

H : 1,8
W1 : 60
W2 : 69,3
L1 : 150
L2 : 81,5

Trapeze Table Top With Grommet

H : 1,8
W1 : 60
W2 : 69,3
L1 : 170
L2 : 101,5

Rectangle Side Table Top

H : 1,8
W : 55
L : 88

Trapeze Side Table Top

H : 1,8
W1 : 35
W2 : 40,5
L : 72,8

Penholder

H : 12,4
W : 11,5
L : 10,2

Box

H : 6,8
W : 11,5
L : 24,2

Paper Tray

H : 7,8
W : 23,5
L : 31,3

Note Holder

H : 37
W : 2
L : 2

Whiteboard

H : 48,2
W : 3
L : 30

Socket Bo

H : 4,5
W : 4,5
L : 23,2

Table Holder

H : 3,3
W : 3,2
L : 9,4

Table Top Grommet Cover

H : 10,4
W : 10,5
L : 3,6

Floor Connection

H : 0,5
W : 80
L : 16

Taple Top Panel Connector

H : 2
W : 4
L : 11

Taple Top Panel Connector

H : 2,5
W : 4
L : 11

MAINTENANCE RECOMMENDATIONS

  • Fabric
  • Metal
  • Plastic
  • Plexiglass
  • Wood
    Fabrics should be periodically dusted with a lightly damp cloth. The accumulated dust over the surface can be cleaned with a vacuum cleaner. In case of stains, they must be wiped with lukewarm water, using cleaners that do not contain intense chemical substances. They should not be brushed.
    Metal surfaces must be wiped with cleaners that do not contain abrasives, and then dried with a soft cloth. Cleaning materials with abrasive chemicals, alcohol or those that are solvent-based should not be used on painted metal surfaces.
    You can clean your products periodically with a damp cloth. In the event of getting wet by a liquid, it must be thoroughly dried with a cloth with high absorbency. Oil stains must first be cleaned with soapy cloth, and then wiped with circular motions using a dry cloth.
    Cleaners that do not contain water and abrasive should be used on plexiglass surfaces, and should be dried with a soft cloth after wiping. The use of cleaning materials containing abrasive chemicals, alcohol or solvents should be avoided.
    Wood surfaces must be wiped regularly with a lightly damp cloth in the direction of its streaks, and then dried with a soft cloth. Polish and cleaner that contain aerosol should not be used.
